SAFESHEATH WORLEY TELESCOPIC LV
Introducer System for Sub-selective LV Access

  • FEATURES

    5 French O.D. Target Vein Selector makes target vessel identification and guide wire placement a snap

    7 French I.D. introducer provides support and stability for easier, reliable delivery of larger, more stable leads despite tortuous anatomy

    Unique combination of proximal and distal curves for sub-selective access to angulated lateral vein branches

    Braided sheath construction for better torque control and stability

    Break-away hub with integrated handle requires no cutting and provides a secure grip during slicing, reducing the risk of lead dislodgement during removal

    Multidurometer construction of proximal curve for improved tip directivity

    Radiopaque tip marker on introducer for enhanced fluoroscopic visualization

    Easy-to-use slicer mates to the SafeSheath hub to create a stable platform for the cutting hand

    Side port for "keep open" infusion and contrast injection

    Reduces risk of blood loss and air embolism

  • DESCRIPTION

    High pacing thresholds, phrenic pacing, lead instability and angulated venous branches can make for difficult and prolonged procedure times, resulting in less desirable lead position and implant failures. The SafeSheath® Worley Telescopic  Lateral Vein Introducer (LVI) System is designed to solve this problem.

    Reduce Implant Times 30-50% Successful Cardiac resynchronization therapy (CRT) requires accurate delivery of the pacing lead to specific postero-lateral epicardial LV pacing sites via the coronary sinus. Available in four unique curves, the LVI provides sub-selective access to the target vein. When combined with our new Target Vein Selector, better, more reliable access to the chosen vessel is achieved, no matter what the situation.

    When deployed through the 7 French I.D. LVI, the 5 French O.D. Target Vein Selector is the easiest way to locate and cannulate the target vein, serving as a “rail” for advancing the LV introducer into the vein.

    For delivery of larger, more stable leads, the 7 French LVI’s braided construction and multidurometer reinforced proximal curve delivers increased torque control and tip directivity, providing needed support and stability during procedures.

    Improved Visualization Contrast injection is easily accomplished with the SafeSheath LVI’s convenient sideport, while the radiopaque tip marker enhances fluoroscopic visualization during procedures.

    Easy Removal The unique, breakaway hub requires no plastic to cut through, reducing the risk of lead dislodgement. One side of the hub has an integrated handle which stays firmly attached to the sheath, helping with control and stability during slicing and removal. Finally, the advanced material of the LVI sheath offers uniform resistance during slicing with the user-friendly cutter.

    Right for All Situations Together, the  SafeSheath CSG, Worley Telescopic LVI and Target Vein Selector help you avoid the problems associated with LV lead placement AND reduce your implant times 30-50%.

  • SPECIFICATIONS

    SAFESHEATH WORLEY TELESCOPIC LV INTRODUCER WITH TARGET VEIN SELECTOR

    Size

    7 French I.D.

    Maximum Outer Diameter

    0.120"

    Minimum Inner Diameter

    0.090"

    Minimum Tip Inner Diameter

    0.090"

    Model

    Shape/Curve

    Length

    LVI/75-5-62-07-RE

    Renal/Compound

    62cm

    LVI/75-5-62-07-HO

    Hook/80°

    62cm

    LVI/75-5-62-07-HS

    Hockey stick/120°

    62cm

    LVI/75-5-62-07-MP

    Multi-purpose/67°

    62cm

    Each SafeSheath Worley Telescopic LV Introducer System kit includes:

    One braided sliceable sheath w/side port

    One target vein selector

    One braided sheath cutter

    One transvalvular insertion tool (TVI)
